Technical Parameter
This laser bar is tailored to serve entertainment venues requiring precise, programmable lighting. It suits nightclub operators, DJ professionals, and event production companies who demand reliable, flexible output from their lighting systems. As a product from experienced laser moving head manufacturer and rgb moving head laser light manufacturers, it supports multi-mode controls (DMX512, sound, master-slave) to sync effects with audio environments and stage choreography. Its robust functionality allows operators to integrate it easily within existing lighting consoles, providing versatile multi-directional illumination for disco lights laser setups and moving laser light configurations in complex show designs.
Equipped with six independent laser heads, this system offers a full RGB spectrum output with a combination of high-intensity red, green, and blue diodes, yielding up to 12W total power at the highest configuration. The laser bar’s dual-axis operation enables comprehensive 240° vertical and 140° horizontal rotation per head, designed for expansive beam coverage. Engineered with 7 high-torque stepper motors and analog modulation, the device ensures precise beam control and smooth dynamic transitions. Power consumption is controlled under 200W to maintain energy efficiency. These specifications underscore its viability in applications requiring stringent performance metrics such as theatre laser light productions and other professional lighting applications.
This product is highly applicable in commercial entertainment contexts, particularly in venues emphasizing atmospheric visuals such as nightclubs and live concert stages. Its adaptability to disco lights laser programming makes it suitable for both permanent installations and mobile event setups. With compatibility for standard DMX512 protocols, the unit integrates seamlessly with complex lighting networks, facilitating synchronized light shows synchronized with sound. The moving laser light function enhances stage visibility and audience engagement, while its construction reliability accommodates frequent transport and rapid deployment in varied technical environments.
The structural design prioritizes modularity with individually adjustable laser heads contributing to extensive coverage capabilities. Constructed with durable housing suitable for repeated transport, the laser bar facilitates easy maintenance and integration into existing theatrical and entertainment lighting rigs. As an established laser moving head manufacturer product, it supports multiple control technologies including RDM bidirectional communication for enhanced configuration and monitoring. These features collectively optimize installation workflows and system scalability for disco lights and 15W RGB laser light configurations within professional event frameworks.
This laser bar offers superior operational stability with controlled power usage and multiple automatic modes that reduce operator overhead. Integration of intuitive control modes enables streamlined synchronization of lighting effects with event dynamics, enhancing user precision in lighting design implementation. The compact dimensions and portable weight further augment its usability for mobile entertainers and clubs requiring flexible moving laser light solutions. The product’s capability aligns with requirements from leading disco laser lights providers aiming to deliver vivid visual experiences reliably and efficiently.
In nightclub settings where dynamic visual effects drive customer engagement, this laser bar serves as a critical component in lighting rig configurations. Its multi-head RGB output and versatile rotation allow comprehensive disco lights laser coverage, creating an immersive environment that responds to sound inputs. The device integrates into automated and DMX-controlled systems, ensuring precise timing and effect coordination with music. These technical capabilities ensure compliance with performance expectations in high-demand nightlife venues and enable operators to deliver consistent, customizable disco laser lights.
For professional DJs and event producers, this laser bar enhances stage presence by delivering vivid, moving laser light effects that respond to live performance cues. Its compatibility with industry-standard control protocols simplifies integration into complex lighting setups typical in concert halls or private events. The system’s controlled modulation and precise motor functions provide essential reliability under continuous operation, ensuring seamless show execution. This makes it a valuable asset for those needing flexible, programmable lighting tools that conform to both theatre laser light and disco lights operational standards.
|
◎Y8-W12000 Configuration：W2000(R638-600mw + G520-500mw + B450-1W) x6pcs Y8-W3000 |
◎Y8-W3000 Configuration：W500(R638-200 + G520-100 + B450-200) x 6pcs |
|
◎Rated Voltage: AC100~240V 50/60Hz; |
◎Power consumption: ≤200W |
|
◎Laser color:RGB full color |
◎Beam diameter: φ15mm |
|
◎Motor: 7pcs 42 high torque stepper motor |
◎Modulation:analog |
|
◎Rotation: Y axis240° rotation, each head 140° rotation |
◎Channel:14/35/42CH |
|
◎Control mode: sound/ automatic/DMX512/ master-slave |
◎Control technology: ① RDM data bidirectional transmission ② DMX 512 upgrade |
|
◎Operating requirement: dry, less dust, 0~35(environmental temperature),will reduce the attenuation of the diode and extend the life of the light. |
◎Application:indoor small medium events |
|
◎2 in1 packing size:114 x 35 x 48cm |
◎N.W./G.W.: 27/31kg |
|
|
Technical Parameter
|
Model |
Item name |
Power |
|
Y8-W12000 |
12W RGB moving head laser bar |
W2000(R600+G500+B1W) x6pcs |
|
Y8-W3000 |
3W RGB moving head laser bar |
W500(R200+G100+B200) x 6pcs |
QUALITY CONTROL
What control options do you offer for the Y8 RGB moving head laser light?
We provide multiple control modes for the Y8, including DMX512, sound activation, automatic programs, and master-slave. This flexibility allows you to tailor lighting effects to your event needs, making it ideal for club laser setups and professional disco laser lights applications.
Can the Y8 laser bar be customized for different event sizes or stages?
Yes, the Y8's six individual laser heads and adjustable dual-axis rotation provide versatile coverage. Its compact design supports indoor small to medium events, making it suitable for a variety of professional moving laser light setups and custom stage designs.
What maintenance is required to ensure long-term performance of the Y8 laser bar?
We recommend operating the laser in a dry, low-dust environment between 0~35°C and regularly cleaning the laser lenses. The unit’s durable build minimizes downtime and supports reliable performance in demanding event environments, highly valued by rgb moving head laser light manufacturers and users.
How do you handle shipping and installation support for orders of the Y8 laser bar?
We ship the Y8 in secure packaging sized 114 x 35 x 48 cm, weighing approximately 31 kg gross. Our technical team can assist with installation guidance and configuration, ensuring your laser moving head manufacturer requirements for professional event use are fully met.
