Feature
The general outdoor waterproof lasers are high-power and high-cost. In order to meet the use of some small outdoor venues, the new D9 series waterproof and low-power was born. Light and small, easy to install, and has a very practical IP65 protection level. It is used in forests and parks.
The laser adopts the intelligent temperature control system independently developed by our company to ensure the normal use under the environment of -20~35°C.
Technical Parameter
Feature
The general outdoor waterproof lasers are high-power and high-cost. In order to meet the use of some small outdoor venues, the new D9 series waterproof and low-power was born. Light and small, easy to install, and has a very practical IP65 protection level. It is used in forests and parks.
The laser adopts the intelligent temperature control system independently developed by our company to ensure the normal use under the environment of -20~35°C.
|
◎D9-W3000: R635-700mW/G525-800mW/B450-1.5W |
◎D9-W2000: R635-500mW/G525-400mW/B450-1.2W |
| ◎Rated Voltage: AC110~220V 50/60Hz; Rated Power：120W@220V |
◎Scanner: 3W25K+,2W20K+ fast scanning system, scan angle:max±30°;Input signal:±5V;Linearity distortion<2% |
|
◎Modulation:analog |
◎Beam diameter and divergence:3*6.5mm;1.5mrad |
|
◎Control mode: auto, master-slave, DMX512(5CH/17CH/18CH/27/52CH), |
◎Control Interface: Waterproof DMX512 interface |
|
◎Demonstration effect: built-in 160 pattern. |
◎DMX effect:double pattern mode,and with the function of unique blanking,strobe, rotation, movement, zoom, write in,speed and color etc. |
|
◎Control technology: ①RDM data bidirectional transmission ② temperature control system ③DMX512 upgrade |
◎Application:water shows, buildings, mountains, northern lights and outdoor stage performances, etc. |
|
◎IP rate:IP65(outdoor) |
◎Package size：32.5*25.5*19CM（1 in 1） 52*34*38.5 cm（2 in 1） |
|
◎N.W./G.W: 3.6kg/9kg（1 in 1） 7.2/17.6kg（2 in 1） |
|
|
|
|
Technical Parameter
|
Model |
Item name |
Laser power |
|
D9-W3000 |
3W RGB mini outdoor laser |
R635-700mW/G525-800mW/B450-1.5W |
|
D9-W2000 |
2W RGB mini outdoor laser |
R635-500mW/G525-400mW/B450-1.2W |
